Sugo SG09 is compatible with Micro-ATX, DTX and Mini-ITX motherboards and it’s made of steel for the body and plastic for the front panel. The dimensions of the SG09 are: 220 mm (W) x 295 mm (H) x 354 mm (D), capacity of 23 liters and weighs 5.3 kg.
SilverStone SG09 supports CPU coolers with hight up to 165mm, two graphic cards with length up to 338mm (13.3 inches) and PSU up to 180mm (recommend 160mm due to varying connector locations on PSUs ). The case offers one external slim drive bay for optical device, 2 x 3.5″ and 4 x 2.5″ realocated to the backside of the motherboard tray.
SG09 has decent options for cooling of the mounted hardware:
Rear: 1 x 120mm 1200rpm 22dBA
Left side: 1 x 120mm 1200rpm 22dBA (backward compatible with 92mm) and 2 x 80/92mm fan slots
Righ sidet: 80mm fan slot
Top: 180mm Air Penetrator 700/1200rpm, 18/34dBA with dual fan switch (backward compatible with 140mm).
On the front panel of the case there are 2 x USB 3.0 and audio ports. For more information please visit the official site of the SilverStone SG09.
