Reeven OKEANOS RC-1402

Reeven OKEANOS RC-1402 heatsink structure

The cooler is formed as a twin tower heatsink with dimensions of 140(W) x 135(D) x 163(H) mm and overall weight of 1145g including the fans. The connection between the contact plate and the fins is done by 4 x Ø6mm and 2 x Ø8mm nickel plated copper heatpipes.

Reeven OKEANOS RC-1402 fans

The cooler is supplied with:

1. 1 x 120 x 25mm fan working at 300 ~ 1800 revolutions per minute (1200 when equipped with SSA (Speed Switch Adaptor)), PWM powered and regulated, providing airflow level of 16.6 ~ 92.5 CFM (63.8 when equipped with SSA), with static pressure level of 0.003 ~ 0.098 inch H₂O (0.042 when equipped with SSA) at noise level of 4.0 ~ 33.4 dBA (23.6 when equipped with SSA).
2. 1 x 140 x 25mm fan working at 300 ~ 1700 revolutions per minute (1100 when equipped with SSA), PWM powered and regulated, providing airflow level of 16.3 ~ 92.4 CFM (59.8 when equipped with SSA), with static pressure level of 0.002 ~ 0.091 inch H₂O (0.034 when equipped with SSA) at noise level of 5.8 ~ 36.4 dBA (21.3 when equipped with SSA).

According to the official technical details, Reeven OKEANOS RC-1402 is compatible with:

1. LGA 775 / 115X / 1366 / 2011
2. AM2 (+) / AM3 (+) / FM1 / FM2 (+)
